10.1 Inch Car Monitor Solar Power Wireless Surveillance CCTV System Camera Security
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | W12-F75-10.1 |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 50,000pcs per month; |
|
Detail Information |
|||
| Product Name: | 10.1 Inch Car Monitor | Screen Size: | 10.1 Inch |
|---|---|---|---|
| Cameras: | 1-4 1080P Wireless Cameras | Screen Type: | TFT |
| Viewing Angle: | 150° | Power Supply: | DC 12V-24V |
| Car Make: | Universal,All Cars,coach,buses,Bus | Working Temperature: | -20℃ To +70℃ |
| Highlight: | 10.1 Inch Car Monitor,Solar Power Car Monitor,Wireless Surveillance Car Monitor |
||
Product Description
10.1 Inch Car Monitor Camera CCTV System Description
10.1 Inch Car Monitor Solar Power Wireless Surveillance CCTV System Camera Security
Transform your vehicle’s safety and convenience with our 10.1 Inch Car Monitor Camera CCTV System, designed for drivers who demand clarity, reliability, and multi-functional monitoring. This advanced system combines a large high-definition screen with versatile camera inputs, making it ideal for personal cars, trucks, commercial fleets, RVs, and more.
10.1 Inch Car Monitor Camera CCTV System Key Features:
1.Ultra-Clear 10.1 Inch IPS Display
- Vibrant 1280x720 HD resolution with wide viewing angles (IPS panel) ensures crisp visuals, day or night.
- Touchscreen or physical button controls (model-dependent) for intuitive operation.
2.Multi-Channel Camera Support
- Supports up to 4 cameras (1 front + 3 optional auxiliary cameras) for 360° coverage.
- Seamless switching between views (front/rear/side) to eliminate blind spots.
3.Enhanced Night Vision & Waterproof Cameras
- Built-in infrared LEDs provide clear 20-30m night vision in low-light conditions.
- IP68-rated waterproof cameras withstand rain, dust, and harsh environments.
4.Smart Parking Monitoring & Motion Detection
- Auto-activates recording upon collision detection or motion near the vehicle (requires hardwired power).
5.Loop Recording & Expandable Storage
- Supports microSD cards (up to 256GB) for continuous loop recording (card not included).
6.Wide Compatibility & Easy Installation
- 12-24V DC input compatible with most vehicles.
- Simple plug-and-play setup with included RCA/AV cables and power harness.
10.1 Inch Wireless Car Monitor Camera Main Features
| System model | W12-F75-10.1 |
| HD Wireless Monitor (MWHD-774H) | |
| Color LCD screen | 10.1-inch IPS screen |
| Wireless reception | Built-in 2.4G wireless receiver |
| Picture mode | 4ch single screen switching + 2 split + 3 split + Quad |
| working frequency | 2400~2483.5MHZ |
| Receiving sensitivity | ≤-86 dB |
| Receiving distance | Open ≤300m |
| Multi-frequency automatic frequency hopping channel code ion | 80 |
| Resolution | 1024(H) X 600(V)dot |
| Color system | PAL/NTSC (AUTO) |
| Brightness(cd/m2) | 600 |
| Load dump | DC24+174V(Td350mS) 5pulses |
| Vibration resistance level | 5G (conforms to GB-T2423056-2006 standard) |
| Working temperature | -20ºC to +70ºC |
| Storage temperature | -30ºC to +80ºC |
| Working voltage | DC8-32V |
| Dimensions | (L x W x T) (218 x 150 x 54mm) |
| 1080P Wireless Camera(CWHD-152M) | |
| Image sensor | 1/2.9 Color DSP |
| Wireless transmission | Built-in 2.4G digital wireless transmitter |
| Transmit power | 18dBm |
| Launch distance | Open area≤100m |
| Resolution | 1080P |
| effective pixels | 1920(H) X 1080(V) |
| Viewing angle | 150° |
| Infrared distance | 15 meters |
| Shell material | Aluminum alloy |
| Waterproof rating | IP68 |
| Working voltage | DC8-32V |
| Working temperature | -20ºC to +60ºC |
| Storage temperature | -30ºC to +70ºC |
| Vibration resistance level | 5G (conforms to GB-T2423056-2006 standard) |
| Dimensions | 106(W) x 75(H) x 70.4(D) mm |
Application Scenarios:
- Passenger Vehicles: Reverse parking aid, blind-spot monitoring.
- Trucks/RVs: Trailer hitching, rear-view surveillance.
- Commercial Fleets: Driver safety monitoring, cargo security.
- Outdoor Adventures: Off-road navigation, campsite security.
Why Choose This System?
- Safety First: Eliminate blind spots and enhance parking precision.
- All-Weather Durability: Rain, snow, or dust—cameras perform reliably.
- User-Friendly: Plug-and-play setup, no professional installation needed.
Versatile Expandability: Add up to 3 extra cameras for full coverage.
FAQ:10.1 Inch Wireless Car Monitor Camera
Q: What is your terms of packing?
A: Generally, we pack our goods in neutral white or natural color gift boxes. If you have legally registered patent, we can pack the goods in your branded boxes after getting your authorization letters.
Q: What is your terms of payment?
A: T/T 30% as deposit, and 70% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q: What is the MOQ ?
A: 1 piece
Q: How fast for sample delivery?
A: 3-7 days
Q: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings.
Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.
Q: How about the warranty period?
A: One year!
Q: How can you guarantee the quality?
A: Our production quality follows the standard of MIL-STD-105E. We have a QC team with 15 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
