8 Channel Mobile DVR 1080P 4G GPS WIFI HDD Card DVR Full HD Car Cameras For City Bus
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW9018B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 5,000pcs per month; |
|
Detail Information |
|||
| Software Support: | Client, Server, Playback Software | Cameras: | Analog Or 720P/960P/1080P Cameras |
|---|---|---|---|
| Mouse Operating: | Support | VGA/AV Output: | Support |
| Storage: | 2TB Hdd Storage+1*sd Card | Language: | English/Chinese/Russian/Spanish/other Language Can Be Customized |
| Video Output: | 8CH AV,1ch VGA+1ch HDMI | Optional Function: | Door Sensor, Oil Sensor And So On, Wifi |
| Basic Function: | 8 Cameras Monitoring With 3G/4G Real Time, GPS Tracking,Wi-Fi | Applicable: | Bus, Truck, Taxi, Cab, Petrol, Excavator, Mining Truck Fleets |
Product Description
8 Channel Mobile DVR 1080P 4G GPS WIFI HDD card DVR Full HD Car Cameras For City Bus
8 Channel Mobile DVR Function
Packed with advanced features, this MDVR revolutionizes bus fleet management:
8 Full HD Channels: Records up to 8 camera feeds simultaneously (interior passenger zones, driver area, exterior views) in crisp 1080P, ensuring complete coverage.
4G & WIFI Connectivity: Enables real-time remote monitoring. Fleet managers can stream live video, access recordings, and receive instant alerts (e.g., sudden stops, door openings) via smartphones/PCs.
GPS Tracking: Tracks bus routes, speed, and stops precisely. Analytics help optimize schedules, reduce fuel consumption, and improve on-time performance.
HDD Card Storage: High-capacity HDD card supports continuous loop recording, safeguarding crucial footage for incident analysis and passenger safety.
City transit operators praise its reliability in harsh environments, user-friendly interface, and ability to enhance passenger security—leading to reduced disputes and improved public trust.
8 Channel Mobile DVR Main Specifications
| Operating System | Linux | |
| Language | English, Chinese or Customized language. | |
| Video Compression | H.264 | |
| OSD | Support time, date, vehicle ID, image, etc. | |
| GUI | OSD Interface |
Can external connect to LCD and set the system specifications by remote |
| Video and Recording | Video Input | 8CH 1080P AHD/Analog/Compound video input, aviation connector, |
| 1.0Vp-p, 75Ω | ||
| Video Output |
1CH Compound video output with optional VGA output, 1.0Vp-p, 75Ω. |
|
| Support 1CH full screen and 4CH division. | ||
| Preview | Single/4CH Pictures Preview, support full screen of event trigger or | |
| back view of car reversing | ||
| Recording | Support 1080P/720P/D1/HD1/CIF, support at maximum 8Channels 1080P | |
| Resolution | ||
| Recording |
Optional Recording for Grade 0-7. 0 is the highest and 7 is the lowest. |
|
| Quality | ||
| Video Rate | PAL:100 fps,CCIR625line,50 scenes | |
| NTSC:120 fps,CCIR525line,60 scenes | ||
| CIF:256Kbps - 1.5Mbps,8 grades image quality for optional | ||
| HD1:600Kbps - 2.5Mbps,8 grades image quality for optional | ||
| D1:800Kbps - 3Mbps,8 grades image quality for optional | ||
|
720P:800Kbps - 4Mbps,8 grades image quality for optional 1080P:2Mbps-6Mbps,8 grades image quality for optional |
||
| Recording Mode | Default automatic video recording, support ignition video recording, | |
| schedule video recording, alarm video recording, etc | ||
| Audio | Audio Input | 8CH Aviation connector inputs |
| Audio Output | 1CH Aviation connector output, Output level:1V - 2V | |
| Compression format | G.726, Speed for 8KB/s | |
| Alarm Input | 4CH level alarm inputs | |
| Alarm Output | 1CH level signal output | |
| Communication Interface | Optional for 1CH RS232 or 1CH RS485 | |
| Wireless Transmission | - | |
| Location /G-sensor | -
|
|
| Video Storage | Storage | Support a 2T 2.5 -inch HDD and 1 256G SD card storage |
| Upgrade | Support SD card local upgrade, remote upgrade automatically | |
| Method | ||
| File Format | H.264 general video format | |
| File System | FAT32 exclusive file system | |
| Video Playback | Video Search | Search recorded video files by recording time and recording method |
| Playback |
Support at max 6 channel synchronous playback, suspend, forward, backward |
|
| Support 2/4/8/16 times speed forward or backward | ||
| Security Management |
User Password or administrator password management, support screen locked |
|
| Expansion functions | TTS Voice broadcast | Support TTS voice broadcast |
| Series port expansion |
Support external equipment connecting for advertising screen, PTZ control, fuel sensor, etc |
|
| Power and Consumption | Power Management |
Self-adaptive wide voltage input, with protect functions for overload, undervoltage, short circuit, reversing connection, etc |
| Support time setting startup/shutdown, delayed power off function | ||
| Power and Consumption | Input Voltage | DC:+8V - +36V |
| Output Voltage | +12V-1.5A,+5V-1.5A | |
| Power-off Protection |
UPS technology to protect all recorded information automatically and make sure the files undamaged in case of sudden power off. |
|
| Consumption | Normal working < 14W, standby < 0.5W | |
| Working environment | Temperature | -20℃ - +70℃ |
| Humidity | 20% - 80% | |
| SD Card Type Series | Dimension | 168*148*65MM |
| Weight |
1.4KG |
|
The complete system includes:
With 15 years of professional experience, we have provided different customized solutions to customers all over the world and are a supplier to many branded companies. Has a strong customization ability, can customize unique products according to customer requirements, one-stop to provide monitoring systems for different transportation, do not need to spend time to purchase matching equipment from other companies.
8 Channel Mobile DVR camera systems Applications
