AHD 1080P 8CH 4G GPS Mobile DVR With Built-In ADAS DSM BSD Algorithm AI Powered
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-M9208-AI |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 50,000pcs per month; |
|
Detail Information |
|||
| Storage Card: | HDD(MAX 2TB)+SD Card(MAX 512G) | Operation System: | Linux |
|---|---|---|---|
| Power Name: | 8 Channel Car Mobile DVR | Customized Logo: | Support |
| Modules: | 4G GPS WIFI | 4G: | Support |
| Mouse Operating: | Support | Gps: | Built-in GPS Module |
| Sd Card: | Support | Vdieo Compression: | H264/H265 |
| Highlight: | AI Powered 4G GPS Mobile DVR,4G GPS Mobile DVR,8CH 4G GPS Mobile DVR |
||
Product Description
AHD 1080P 8CH 4G GPS Mobile DVR With Built-In ADAS DSM BSD Algorithm AI Powered
Product Description
The 8CH AI Mobile DVR is a cutting-edge surveillance solution designed for vehicles and mobile applications. With advanced AI capabilities, this device enhances security and monitoring, making it ideal for fleet management, public transportation, and outdoor security.
Key Features:
-
8-Channel Recording: Supports up to 8 cameras simultaneously, allowing comprehensive coverage of the vehicle's surroundings.
-
AI Technology: Equipped with intelligent video analysis, including motion detection, facial recognition, and license plate recognition, to enhance security and reduce false alarms.
-
High-Definition Video Quality: Records in full HD (1080p) to ensure clear and detailed footage, crucial for identifying incidents and monitoring activities.
-
Robust Design: Built to withstand harsh environments, the DVR is resistant to shocks, vibrations, and extreme temperatures, making it perfect for mobile use.
-
Remote Access: Users can access live feeds and recorded footage remotely via a secure mobile app or web interface, facilitating real-time monitoring and management.
-
Multiple Storage Options: Supports various storage solutions, including hard drives and SD cards, with ample capacity for extended recording periods.
-
GPS Tracking: Integrated GPS functionality enables real-time location tracking of vehicles, enhancing fleet management and security.
-
User-Friendly Interface: Intuitive menu navigation and easy setup process for quick installation and operation.
Applications:
- Public transportation
- Fleet management
- Emergency vehicles
- Construction vehicles
- Outdoor surveillance
Main Specification
| Item | Description | |
| Model | VW9208-AI | |
| OS | Linux3.18 | |
| Operating | Cell phone APP, PC client, Remote controller | |
| Functions Summary | Preview, recording, playback, network transmission, positioning, AI analysis, multiple sensor data acquisition. | |
| Video and Preview | Video Input, Output,Signal standard | AHD input:4ch 1080p/25fps, 4ch 720p/25fps, 4ch D1/25fps, IPC input:1ch default, externally expandable 1-4ch, Output: 1ch CVBS default, VGA optional(1024x768) Signal standard:1.0Vp-p, 75Ω, NTSC/PAL optional |
| OSD | Character superposition function, information superposition of time and date, device ID and GPS, alarm,etc. | |
| Video Compression Format | Compression coding. Applying H264/H.265 hi-performance processor. | |
| Image quality | Code stream, frame rate optional | |
| Preview | 1/4/6/8/9 channel preview | |
| Resolution |
AHD: 1080P:25fps/1M/2M/4M/6M 720P: 25fps/1M/2M/4M/6M D1:25fps/512K/1M/2M IPC: 1080P: 30fps/1M/2M/4M/6M
720P: 30fps/1M/2M/4M/6M |
|
| Audio | Audio Input, Output | 4ch analog audio input, 1ch mic input; 2ch audio output. 2.0Vp-p, 4.7kΩ |
| Compression Format | G.711A, G.726 | |
| Recording | Storage Medium | Supporting one 2.5” SATA hard drive and one SD card |
| Video Strategies | Recording at start up by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording | |
| Alarm pre-recording | 0-60min | |
| Alarm recording delay | 0-30min | |
| Playback channel | Support local 1/4/6/8 channel playback | |
| Browse mode | Time, channel, event. | |
| Communication Ports | RS232, RS485 | |
| ADAS | Built-in (Optional) | |
| Wireless Transmission |
3/4G/5G wireless transmission module, EVDO/TD-SCDMA/WCDMA/TDD-LTE/FDD-LTE ect. Wi-Fi module, 802.11b/g/n,2.4G/5.8G optional. Ethernet: Network aviation head(100M) |
|
| Position | GPS/BD: Positioning, speed detection, time synchronization | |
| Power Supply and Power Consumption | Power Supply | 1ACC on/off |
| Input Voltage | DC:+8V ~ +36V | |
| Output Voltage | +12V@1A; +5V@1A | |
| Power Consumption | Max 25W consumption, about 0W in standby mode | |
| Operating Environment | Temperature | preheating: -20℃ ~ +70℃ |
| Humidity | 8% to 90% | |
| Dimensions | 324.6x238x116 mm. | |
| Weight | Net: 2KG | |
Products Details
FAQ
What are the key features?
- 8 Channel Recording: Supports up to 8 cameras.
- AI Technology: Provides features like motion detection, object recognition, and alerts.
- Mobile Compatibility: Ideal for vehicles such as buses, trucks, and emergency vehicles.
- GPS Tracking: Integrates GPS for location tracking of recorded footage.
- Remote Access: Allows users to view live feeds and recordings via mobile apps or web browsers.
How is the installation process?
- Installation typically involves mounting the DVR in a secure location within the vehicle, connecting the cameras, and wiring them to the power supply. Detailed instructions are included in the user manual.
Can I access the footage remotely?
- Yes, the 8CH AI Mobile DVR supports remote access through a mobile app or web portal, allowing you to view live streams and recorded footage from anywhere.
What storage options are available?
- The DVR supports various storage options, including SD cards and external hard drives, depending on the model. Always check the specifications for compatible storage sizes.
Is it compatible with all cameras?
- The DVR is compatible with most analog and IP cameras. Ensure that your cameras meet the specifications outlined in the product manual.
Does it require a constant internet connection?
- While remote access benefits from a stable internet connection, the DVR can function independently without one. Recorded footage is stored locally and can be accessed later.
What kind of warranty is offered?
- Warranty details vary by manufacturer, but most offer a standard one-year warranty covering defects in materials and workmanship. Check the specific warranty policy for your model.
How does the AI feature enhance security?
- AI features improve security through intelligent analysis, such as detecting unusual activity, recognizing faces, and sending alerts to users, allowing for proactive monitoring.
