4CH 4G HDD Mobile DVR GPS WiFi Live Video Car CCTV DVR Truck Cmsv6 System
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-812HD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 50,000pcs per month; |
|
Detail Information |
|||
| Product Name: | 4 Channel Hd Mobile Dvr With Cmsv6 Client Software | Video Compression: | H. 264 |
|---|---|---|---|
| Video Input: | 4 Channels | Resolution: | 1080P/720P |
| Storage: | 1*2TB HDD+1*256GB SD Card | Language: | English/Chinese/Russian |
| Power Supply: | DC 8-36V | Warranty: | 18 Months |
| Gps: | Support | Operating Temperature: | -20℃~+70℃ |
| Highlight: | 4CH 4G Mobile DVR,GPS WiFi 4G Mobile DVR,Live Video Car CCTV DVR |
||
Product Description
4CH HDD Mobile DVR Description
4CH 4G HDD Mobile DVR GPS WiFi Live Video Car CCTV DVR Truck Cmsv6 System
The 4CH 4G GPS Mobile DVR is a cutting-edge, multi-channel digital video recorder designed for vehicle surveillance and fleet management. Equipped with advanced 4G connectivity and GPS tracking, this device ensures real-time monitoring, recording, and location tracking, making it an ideal solution for enhancing security and operational efficiency.
4CH HDD Mobile DVR Key Features
1.4-Channel Video Input: Supports up to four cameras, allowing comprehensive coverage of the vehicle's interior and exterior. This ensures all angles are monitored for maximum security.
2.4G LTE Connectivity: Enables real-time video streaming and remote access via mobile apps or web browsers. Stay connected to your vehicle's surveillance system from anywhere, anytime.
3.Built-in GPS Tracking: Provides accurate real-time location tracking, route history, and speed monitoring. Perfect for fleet management and ensuring driver accountability.
4.High-Quality Video Recording: Captures crystal-clear footage in high resolution, even in low-light conditions. Supports loop recording and automatic overwrite of old files when storage is full.
5.Wide Storage Capacity: Compatible with large-capacity hard drives or SD cards, ensuring extended recording times without the need for frequent data transfers.
6.Motion Detection & Alerts: Advanced motion detection technology triggers instant alerts and recordings when movement is detected, enhancing security and reducing unnecessary footage.
7.Durable & Compact Design: Built to withstand harsh environments, the device is shockproof, dustproof, and resistant to extreme temperatures, making it suitable for all types of vehicles.
8.Easy Installation & User-Friendly Interface: Simple setup process with an intuitive interface for easy operation and configuration.
4CH HDD Mobile DVR Specification
|
Item |
Description |
||
|
OS |
Linux |
||
|
Graphics Operation Interface |
System parameters can be set through external display and remote controller |
||
|
Security Management |
2-level management for user password, administrator password, supporting encrypted transmission |
||
|
Video and Preview |
Video Input, Output |
4-channel video input, 1channel video output; 1.0Vp-p, 75Ω |
|
|
OSD |
Character superposition function, information superposition of time and date, device ID and GPS, etc. |
||
|
Video Compression Format |
Compression coding. Applying hisilicon hi-performance processor. |
||
|
Dual-Stream |
Supported |
||
|
Preview Function |
Preview of 1-channel, 4-image stitching, supporting full screen triggered by event and switching of stitched images |
||
|
Frame Rate |
PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel |
||
|
Resolution |
CIF, HD1 and D1 for selection, supporting 2 channels of D1+ 2 channels of CIF at the most |
||
|
Quality |
Grade 1 to grade 5 for selection (descending) |
||
|
Bit Rate |
CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection |
||
|
Audio |
Audio Input, Output |
4-channel input, 1-channel output |
|
|
Compression Format |
G.726 coding |
||
|
Recording |
Storage Medium |
Supporting one 2.5” hard drive and one SD card, which supports up to 32G, supporting data redundancy storage technology; |
|
|
File Format/ System |
ASF/FAT32 |
||
|
Video Strategies |
Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording |
||
|
Video Search |
Searching by time, type, storage device and other conditions |
||
|
Video Playback |
Supporting playback on local device, supporting synchronous playback of up to 4 channels and analysis on vehicle information in the files |
||
|
Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time |
|||
|
Alarm |
Alarm Input/ Output |
6-channel on/off signal alarm input, 1-channel on/off signal alarm output |
|
|
Alarm Recording |
Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30min |
||
|
Storage Space Alarm |
Supporting settings for alarm of storage space |
||
|
Function Alarm |
GPS overspeed alarm, acceleration alarm, motion detection alarm |
||
|
Communication Ports |
RS232, RJ45 10M/100M self-adaptable network interface |
||
|
Wireless Transmission (Optional) |
Supporting Wi-Fi; |
||
|
GPS (Optional) |
Supporting external GPS |
||
|
PTZ Control |
Supporting PTZ control realized by local; |
||
|
Parameter Configuration |
Supporting parameter configuration functions for mobile DVR coding channel; |
||
|
G-Sensor |
Embedded |
||
|
System Upgrading |
Supporting SD card, hard drive upgrading and remote upgrading |
||
|
Power Supply and Power Consumption |
Power Supply |
1. ACC on/off 2. Hard drive lock on/off 3. Delayed shutdown 4. Timed on/off |
|
|
Input Voltage |
DC:+8V ~ +36V |
||
|
Output Voltage |
+12V@4*0.5A; +5V@0.5A |
||
|
Power-off Protection |
With patented UPS power supply continuous working technology, it can work for 3~5 seconds after external power supply is cut so that the intactness of video data can be kept upon sudden power failure |
||
|
Power Consumption |
<10W in normal operation; <0.5W in standby mode |
||
|
Operating Environment |
Temperature |
Normal: 0℃ ~ +60℃; upon hard drive preheating: -25℃ ~ +60℃ |
|
|
Humidity |
10% to 95% |
||
|
Dimensions |
160(W) x62(H) x200(D) mm. |
||
|
Weight |
Net: 2200g, Gross: 3500g |
||
Applications:
- Fleet management and tracking
-
Public transportation security
-
School bus monitoring
-
Personal vehicle protection
-
Logistics and delivery services
FAQ
Q1.How many cameras can I connect to the DVR?
The device supports up to 4 cameras, allowing you to monitor both the interior and exterior of your vehicle simultaneously.
Q2.Does the DVR require an internet connection?
Yes, the 4G LTE connectivity allows real-time video streaming and remote access. However, the device can still record footage locally (on an SD card or hard drive) without an internet connection.
Q3.Can I access the DVR remotely?
Yes, you can access the DVR remotely via a mobile app or web browser. The 4G connectivity enables live video streaming, playback, and GPS tracking from anywhere.
Q4.How does the GPS tracking work?
The built-in GPS module provides real-time location tracking, route history, and speed monitoring. This data can be accessed remotely through the app or software.
Q5.What storage options are available?
The DVR supports large-capacity SD cards or external hard drives for local storage. It also features loop recording, which automatically overwrites old footage when the storage is full.
Q6.Is the DVR compatible with night vision cameras?
Yes, the DVR is compatible with night vision cameras, ensuring clear footage even in low-light or nighttime conditions.
Q7.How durable is the device?
The DVR is designed to withstand harsh environments. It is shockproof, dustproof, and resistant to extreme temperatures, making it suitable for use in various vehicles.
Q8.How do I install the DVR?
Installation is straightforward. Mount the DVR in your vehicle, connect the cameras, and configure the settings via the app or software. Detailed instructions are provided in the user manual.
