OEM 8CH HD 1080P HDD Mobile DVR With 4G GPS WIFI MDVR For Fleet Management System
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-812HD |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1 pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 50,000pcs per month; |
|
Detail Information |
|||
| Product Name: | 8CH HDD Mbilbe DVR | Resolution: | 8 Channel |
|---|---|---|---|
| Operating System: | LINUX | Shockproof: | Dual Anti-vibration |
| Video Compression: | H. 264/H.265 | Warranty: | 18 Months |
| Storage: | 2TB HDD Storage+1*SD Card | Language: | Chinese,English,Russian,Multi-Language |
| Power Input: | DC 8V~36V | Optional Function: | Oil Sensor,Fuel Sensor,Temperature&Humidity Sensor,Shockproof,4G,WIFI,GPS |
| Highlight: | 8CH HD 1080P Mobile DVR,4G GPS WIFI Mobile DVR,Fleet Management System Mobile DVR |
||
Product Description
8CH Full HD 1080P HDD Mobile DVR Product Description
OEM 8CH HD 1080P HDD Mobile DVR With 4G GPS WIFI MDVR For Fleet Management System
The OEM 8CH 1080P HDD Mobile DVR is a high-performance mobile digital video recorder designed for vehicle surveillance. It provides reliable and secure recording capabilities for up to 8 channels, ensuring comprehensive coverage for your fleet or personal vehicles.
8CH 4G HD Mobile DVR Key Features
-
8 Channel Recording: Supports up to 8 channels of 1080P video recording, allowing you to capture high-definition footage from multiple cameras simultaneously.
-
High Definition Video: Records in 1080P resolution, delivering clear and detailed images for accurate monitoring and playback.
-
HDD Storage: Equipped with a robust hard disk drive (HDD) for ample storage capacity, enabling extended recording times without the need for frequent data transfer.
-
Mobile Application: Compatible with mobile applications for real-time viewing and remote management, ensuring you can monitor your vehicles from anywhere.
-
G-Sensor Technology: Integrated G-sensor detects sudden movements or impacts, automatically saving the footage to prevent data loss.
-
User-Friendly Interface: Intuitive interface and easy-to-navigate menus make setup and operation straightforward for users of all skill levels.
-
Multiple Playback Options: Supports various playback modes, including single-channel, multi-channel, and time-lapse, for flexible review of recorded footage.
4G 8CH Mobile DVR CCTV Main Features
| Professional Car Power Design,8-36V wide voltage,Provide reverse voltage/overload/short circuit protection |
| 2TB HDD / SSD ,protect DVR from shock & Dust damage; |
| Exclusive File System protect data completeness; |
| ACC Delay off,can set 3- 255 mins to work; |
| Unique UPS Technology ensures the integrality of record when power failure occurs,even can for 8-10s. |
| Support GPS/GLONASS,3G/4G Module Optional,WIFI extend; |
| Support Monitoring,Intercom, PTZ, Alarm,Overspeed,Geo Fence etc through remote control platform; |
| 8CH Alarm inputs(Door Open,Light,Turn direction,brake,reverse etc),can linkage kinds of alarm; |
| High level aviation interface,easily installation and better shockproof, more stable; |
| Easily Smart GUI Interface, saving time in device setting; |
4G 8CH Mobile DVR CCTV Main Features
| Item | Description | |
| OS | Linux | |
| Graphics Operation Interface | System parameters can be set through external display and remote controller | |
| Security Management | 2-level management for user password, administrator password, supporting encrypted transmission | |
| Video and Preview | Video Input, Output | 8-channel video input, 1channel video output; 1.0Vp-p, 75Ω |
| OSD | Character superposition function, information superposition of time and date, device ID and GPS, etc. | |
| Video Compression Format | Compression coding. Applying Hisilicon hi-performance processor. | |
| Dual-Stream | Supported | |
| Preview Function | Preview of 1-channle, 4-image stitching, supporting full screen triggered by event and switching of stitched images | |
| Frame Rate | PAL: 100 frames/s, up to 25 frames/s per channel; NTSC: 120 frames/s, up to 30 frames/s per channel | |
| Resolution | AHD 1080P/ 720P, D1, CIF 4channel | |
| Quality | Grade 1 to grade 5 for selection (descending) | |
| Bit Rate |
CIF: 256Kbps ~ 1.5 Mbps, 8-level bit rates for selection HD1: 600Kbps ~ 2 Mbps, 8-level bit rates for selection D1: 800Kbps ~ 3Mbps, 8-level bit rates for selection 720P: 2048Kbps~6144Kbps |
|
| Audio | Audio Input, Output | 8-channel input, 1-channel output |
| Compression Format | G.726 coding | |
| Recording | Storage Medium | Supporting one 2.5” hard drive and one SD card, which supports up to 128G, supporting data redundancy storage technology; |
| File Format/ System | Special file system | |
| Video Strategies | Recording at startup by default, supporting timed recording, recording triggered by alarm and event, as well as manual recording | |
| Video Search | Searching by time, type, storage device and other conditions | |
| Video Playback | Supporting playback on local device, supporting synchronous playback of up to 4 channels and analysis on vehicle information in the files | |
| Supporting fast forward, fast backward, play and pause, supporting fast forward and fast backward at 2x, 4x, 8x and 16x speed, supporting file play from selected time | ||
| Alarm | Alarm Input/ Output | 8-channel on/off signal alarm input, 1-channel on/off signal alarm output |
| Alarm Recording | Prerecording function 15 seconds before alarm, duration of recording after alarm can be adjusted from 30s ~ 30min | |
| Storage Space Alarm | Supporting settings for alarm of storage space | |
| Function Alarm | GPS overspeed alarm, acceleration alarm, motion detection alarm | |
| Communication Ports | RS485,RS232, RJ45 10M/100M self-adaptable network interface | |
| Wireless Transmission (Optional) | Supporting Wi-Fi; | |
| GPS (Optional) | Supporting external GPS | |
| PTZ Control | Supporting PTZ control realized by local; | |
| Parameter Configuration | Supporting parameter configuration functions for mobile DVR coding channel; | |
| G-Sensor | Embedded | |
| System Upgrading | Supporting SD card, hard drive upgrading and remote upgrading | |
| Power Supply and Power Consumption | Power Supply |
1. ACC on/off 2. Hard drive lock on/off 3. Delayed shutdown 4. Timed on/off |
| Input Voltage | DC:+8V ~ +36V | |
| Output Voltage | +12V@5*0.5A; | |
| Power-off Protection | With patented UPS power supply continuous working technology, it can work for 3~5 seconds after external power supply is cut so that the intactness of video data can be kept upon sudden power failure | |
| Power Consumption | <10W in normal operation; <0.5W in standby mode | |
| Operating Environment | Temperature | Normal: 0℃ ~ +60℃; upon hard drive preheating: -25℃ ~ +60℃ |
| Humidity | 10% to 95% | |
| Dimensions | 160(W) x62(H) x200(D) mm. | |
| Weight |
Net: 2200g, Gross: 3500g |
|
About Us
FAQ for 8CH HDD Mobile DVR
Q1. What is the resolution of the video recording?
The OEM 8CH Mobile DVR supports 1080P resolution for high-quality video recording.
Q2. How many channels does this DVR support?
This model supports up to 8 channels, allowing you to connect multiple cameras simultaneously.
Q3. What type of storage does it use?
The DVR is compatible with HDD storage, allowing for substantial data storage capacity.
Q4. Can I access the recordings remotely?
Yes, the DVR supports remote access, enabling you to view live footage and recorded videos from anywhere via a smartphone or computer.
Q5. Is the DVR suitable for vehicle use?
Absolutely! This mobile DVR is designed for use in vehicles, making it ideal for fleet management and mobile surveillance applications.
Q6. What are the power requirements?
The DVR typically operates on a 12V power supply, suitable for most vehicles.
Q7. Does it come with a warranty?
Yes, the OEM 8CH Mobile DVR usually comes with a standard warranty. Please check with the retailer for specific warranty details.
Q8. How is the installation process?
Installation is straightforward, with a user manual included. It’s recommended to have a professional install it for optimal performance.
Q9. What formats does the DVR support for video playback?
The DVR supports various formats for playback, ensuring compatibility with most media players.
Q10. Is technical support available?
Yes, technical support is available to assist with any issues or questions you may have during installation or operation.
