4G Front Camera Bus Dashboard Camera with 1080P Resolution and 4K Wifi Night Vision
Product Details:
| Place of Origin: | Guangdong,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW-210B |
Payment & Shipping Terms:
| Minimum Order Quantity: | 5pcs |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 5,0000 pcs per month |
|
Detail Information |
|||
| Type: | Front Camera/ADAS Camera | Feature: | Windshield, Dustproof |
|---|---|---|---|
| Video Format: | PAL/NTSC Optional | Resolution: | 1080P（1920*1080） |
| Images: | Erect Image | Wire Rod: | 4PAviation Female Head Wire |
| Power Input: | DC12V | Operating Temperature: | -25°C ~ 70°C |
| Operating Humidity: | Less Than 90% | Car Make: | Truck, Bus, Heavy Duty, Trailer And Ect |
| Highlight: | 1080P Resolution Bus Dashboard Camera,4G Front Camera Bus Dashboard Camera |
||
Product Description
Bus Camera 1080P 4G Front Facing Dashboard Camera 4K Wifi Global Positioning System Night Vision
Details of car dashboard camera:
4G Dashcam 1080P camera supporting real-time video monitoring for car and tractor video recorders.
A 128GB (maximum) TF card can be inserted for storing videos and recording up to 56 hours of video.
You can download this data on our tracking platform
1. Real time location tracking:
GPS&BD dual-mode positioning can record vehicle trajectories.
2. Real time video/audio tracking:
After the device is powered on, the system automatically starts recording videos. 1080P resolution high-definition loop video.
3. Vibration alarm:
After ACC off detects vehicle vibration, immediately trigger the vehicle vibration alarm and upload it to the platform.
At the same time, upload photos and wake up the device to record for five minutes.
4. Support collision alarm and accident recording;
5. Support emergency call and alarm
6. Remote viewing of historical videos;
7. Automatically record video after detecting vibration;
8. Enter sleep mode after turning off the ignition;
9. Geofence alarm;
10. Mileage counting.
11. Resend data from LTE/GSM signal blind spots (supporting storage of up to 300 location points);
Front Camera Technical Specification
| AHD Cameras:VW-210B | |
| Technology | infrared |
| Sensor | 1/3 AHD 1080P |
| Shape | Streamlined camera |
| Types | Front view camera |
| Installation | Screw and 3M Glue |
| Lens | 2.8MM/3.6MM |
| Power | DC12V/24V |
| Color | Black |
| Connector | 4 PIN connector or RCA connector |
| Material | aluminium alloy |
| Effective Pixels | 720P/130W 1080P/200W |
| Operating Temperature | -25℃~70℃ |
| Warranty | 1 Years |
| Chip Technical Parameters | |||
| Image Sensor | 1/2.9" IMX323 2.0MP | Video Out | 1CH BNC AHD output, Support TVI/CVI/CVBS Mode |
| Image System | PAL/NTSC | WDR | auto |
| Resolution | 1920 (H)×1080(V) | SNR | >45db |
| Min.illumination | 0.01Lux full color | White Belance | AWB |
| Electronic Shutter | 1/25s~1/100,000s | DR | 76db |
| Video Standard | AHD | Advanced Function | 2D_DNR |
| Frame Rate | 1920×1080@25 fps; 1920×1080@30 fps; |
Working Environment | -25℃~+70℃,Humidity 95% |
| Lens | 2.1/2.8/3.6 | Power supply | DC 12V +/-15% |
Connetor Available for Option
- 4Pin Aviation connector
- DC+RCA connector
- CCTV security BNC+DC connector
Bus security Cameras Accessories
Manual 1pcs, glue 2 pcs
FAQ:
Q: What is the MOQ ?
A: 1 peice
Q: How fast for sample delivery?
A: 3-7 days
Q: Can I get a lower price if I order large quantities?
A: Yes, the larger the quantity, the cheaper the prices.
Q: How about the warranty period?
A: One year!
Q: How can you guarantee the quality?
A: We have a QC team with 12 years’ experience. All of the products will run through over 4 times’ 100% testing before being delivered.
