1080p Hybrid Mnvr 12 Channel mobile ip dvr Video Surveillance Train Digital MDVR
Product Details:
| Place of Origin: | Shenzhen,China |
| Brand Name: | Vanwin Tracking |
| Certification: | CE/FCC/RoHS |
| Model Number: | VW9208N |
Payment & Shipping Terms:
| Minimum Order Quantity: | 1pc |
|---|---|
| Price: | negotiated |
| Packaging Details: | Neutral carton box package by default. Customize package is available if order reach 300 pcs. Customize Logo printing is available for order over 100 pcs . |
| Delivery Time: | 2-3 days for samples,15-30 days for large orders |
| Payment Terms: | T/T or western Union or Paypal |
| Supply Ability: | 5,000pcs per month |
|
Detail Information |
|||
| Features: | 4G And GPS , WIFI, WIFI AP, I/O, RS232/485, AI, Basic Monitoring | Power Supply: | 8V-36V |
|---|---|---|---|
| Video Input: | 4CH AHD 1080P+8CH IPC 2MP-5MP | Storage Capacity: | SSD/HDD+SD, Max 1TB+256GB |
| I/O Cables: | 4ch Alarm Inputs And 2 Ways Outputs | Applicable: | Bus, Truck, Taxi, Cab, Petrol, Excavator, Mining Truck Fleets |
| AVI/H.264 /H.265format: | Support | ||
| Highlight: | 12 Channel Mobile DVR,Hybrid Mnvr Mobile DVR,1080p Digital MDVR |
||
Product Description
1080p Hybrid Mnvr 12 Channel mobile ip dvr Video Surveillance Train Digital MDVR
Specification
MNVR
●4CH MDVR with HUB to expand to 12CH Hybraid MNVR (4CH AHD+8CH IPC)
●Support HDD/SSD+ SD card storage
● Support WIFI, WIFI AP, 3G, 4G;GPS
● Through the preset interface, the acceleration sensor, temperature sensor, oil quantity, control panel, LED screen and other peripheral devices can be connected;
● Support IP voice intercom;
● Small size, with protection box to protect the host
● Support wired network and expandable NVR(can be 4 AHD+８ IPC input)
●Connected to a camera or router, network bandwidth: 100Mbps
●Internal power consumption of the device: bare metal ≤ 0.5W, full function ≤ 0.3W
FAQ
1.Q: Does the MDVR support Hard drive and SD card?
A: Yes, HDD version MDVR supports SSD, HDD, and SD card. SD card version MDVR supports max 2 SD card. The storage capacity can be from 32GB to 2TB.
2.Q: Is it difficult to install MDVR into the vehicle?
A: Actually it is easy to install it into vehicle. Most driver can figure out how to connect the power cables.
And the camera installation is more easy. Just screw, connect and mount on the target place inside the vehicle.
3.Q: If I need door open and close alarm, overspeed alarm, reverse video, brake video, left-turn video, right-turn video, etc,
is it available?
A: Definitely yes!
The I/O RS232 and 485 extension port is for all expanded purposes, including the functions above.
In fact, there are more customized functions which can be connect through this port, such as Fuel sensor, Counter system,
PTZ camera, and so on.
4.Q: We have our own platform and server, can we use your MDVR? Do you have SDK or can you do customized platform for us?
A: Yes, we have SDK ready and welcome your OEM customized order!
